| MOQ: | 10 |
| السعر: | 1 |
| Attribute | Value |
|---|---|
| Model NO. | YH10CX5-110 |
| Installation | Parallel Arrester |
| Application | Substation |
| Size | Medium |
| Operation Voltage | High Voltage |
| Material | ZnO |
| Brand | Yongde |
| Breaking Capacity | High Voltage Circuit Breakers |
| Voltage | 126 |
| Specification | IEC60099-4 |
| Production Capacity | 5000PCS/Year |
| Type | Nominal System Voltage | Rated Voltage | Continuous Operating Voltage | MRV under 1/5 μs Steep Discharge Current | MRV under 8/20 μs Lightning Discharge Current | MRV under 30/60 μs Operating Discharge Current | Minimum Reference Voltage under 1 mA DC | 4/10 μs High Current Impulse Twice (KA) | 2mS SW through-flow capacity A/18 |
|---|---|---|---|---|---|---|---|---|---|
| YH10W5-100/260 (L) | 110 | 100 | 78 | 291 | 260 | 221 | 600 | ||
| YH10W5-102/266 (L) | 110 | 102 | 79.6 | 297 | 266 | 226 | 600 | ||
| YH10W5-108/281 (L) | 110 | 108 | 84 | 315 | 281 | 239 | 600 |
